S 7000 profile system

for a comfortable living environment

The S 7000 profile system has an installation depth of 74 mm. The ingenious interior design with five chambers optimises the thermal insulation whilst special features meet aesthetic requirements.

Benefits of S 7000

Five chamber design

The five chamber interior design prevents the formation of thermal bridges, which optimises thermal insulating performance. The central gasket stop features hollow chambers, thus the profile package has five chambers end to end, including in the rebate area. The certified U value of the profile combination including standard steel stiffening element of Uf = 1.2 W/(m²K) is extremely low.

Special features

A window can only be as attractive as the profile system on which it is based. That is why we added some special features to our S 7000 exclusive profile. This means that your windows will meet all of your customers' aesthetic requirements: harmonious proportions, rounded shapes, narrow visible widths and shining, smooth surfaces.

Narrow profile view

Windows with narrow profile views let in more light. The S 7000 profile system reinforces this effect with very narrow sash and mullion sightlines to give the windows a delicate appearance. Large stiffening elements in the profiles ensure stability despite the slim design.

Anti-burglary protection

GEALAN offers anti-burglary protection as standard with its "S 7000 security profile". The profile installation depth of 74 mm, material strength and central gasket stop as an additional barrier are design features that inherently provide an impressive level of security. They are augmented by secure fastening of the hardware in the frame.

Comfort and well-being

Security

Anti-burglary protection with the S 7000 system

The S 7000 "security profile" offers anti-burglary protection as standard. This is because the large profile installation depth of 74 mm, material strength and central gasket stop as an additional barrier are design features that inherently provide an impressive level of security.

They are augmented by secure fastening of the hardware in the sash. S 7000 was the first profile system to successfully undergo a series of break-in tests by an authorised test institute.


  • Provides additional protection against the window being forced open with tools like screwdrivers or crowbars.
  • The double walls of the sash hardware groove provide a particularly secure seat for the screws and hardware and also counteract attempts to force open the window.

Heat insulation

Five chambers as standard

Rising energy costs are becoming a huge cost factor, and not only in the residential sector. Environmental legislation is also raising the heat insulation standards that windows need to meet. The S 7000 profile system was therefore designed with an installation depth of 74 mm.

The ingenious interior design of the five chambers prevents the formation of thermal bridges and in this way optimises the heat insulating performance. In addition, the central gasket stop features hollow chambers. This means that the profile package has five chambers end to end, including in the rebate area. A certified U value with standard steel stiffening elements of Uf = 1.2 W/(m²K) provides the groundwork for windows with high heat insulation.


  • Outstanding heat insulation (Uf = 1.2 W/(m²K))
  • Option of optimum basic air exchange with GECCO
  • Narrow visible widths
  • Good anti-burglary protection
  • Good statics
  • Weldable, extruded gaskets in papyrus white or black
  • Same stiffening elements in the frame and sash
  • Dimension between axes 13 mm as in the S 8000 system
  • Same hardware as the S 8000 system
  • Many of the same connection profiles as the S 8000 system
  • Available in numerous GEALAN-acrylcolor® colours and (wood grain) decor foils

Colouring in the S 7000 system

The S 7000 profile system offers planners and architects unlimited creativity. All profiles are available in a large number of GEALAN-acrylcolor® colours, wood grain decors and plain foils. Accessory and coupling profiles permit the construction of large elements.

GEALAN-acrylcolor® Standard Colours S 7000

RAL 7016: Anthracite
RAL 9005: Deep black
DB703*

RealWood - exclusive wood decor foil

Realwood Turner Oak malt
Realwood Ginger Oak
Realwood Honey Oak
Realwood Weissbach Oak
Realwood RAL 7016
Realwood RAL 9010

These foils are not made of real wood.

Standard decor foils

Hazelnut
Golden Oak
Deco RAL 7016 Grained – Anthracite Grey
Mahogany

Non-standard: Plain colours, grained

Deco RAL 3005 – Wine Red
Deco RAL 3011 – Brown Red
Deco RAL 5011 – Steel Blue
Deco RAL 6005 – Moss Green
Deco RAL 6009 – Fir Green
Deco RAL 7001 – Silver Grey
Deco RAL 7012 – Basalt Grey
Deco RAL 7023 – Concrete Grey
Deco RAL 7035 – Light Grey
Deco RAL 7039 – Quartz Grey
Deco RAL 9001 – Cream White
Deco RAL 9003 - Brilliant White
Deco RAL 9010 – Pure White
Black Brown
Chocolate Brown
Monument green

Non-standard: Wood decor foils

Oregon
Rustic oak
Moor Oak
Dark Oak
Mountain Pine
Douglas Striped
Light Oak
Meranti
AnTEAK
Walnut
Sheffield Oak Light
Winchester XA

Non-standard: Plain colours, smooth

Deco RAL 7016 Smooth – Anthracite Grey
Deco RAL 7012 – Smooth Basalt Grey
Deco RAL 7021 – Smooth Black Grey
Deco RAL 7039 – Smooth Quartz Grey

Non-standard: Metallic effect foils

Alux DB703
Platinum Bronze
Metbrush Silver
Metbrush Brass

Non-standard: Plain colours, matt

RAL 9010: Pure White matt
RAL 9001: Cream White matt
Black matt
Black Brown matt
RAL 7016: Anthracite Grey matt
